SunGoldPower 3000W 24V Pure Sine Wave Solar Inverter Charger
SunGoldPower 3000W 24V Pure Sine Wave Solar Inverter Charger

Specs

Main Features

  • Built-in 60A MPPT solar charge controller, max PV input 1400W
  • 40A Smart AC charger
  • High frequency transformer-less compact design
  • Pure sine wave AC 120V output with 50hz/60hz switch
  • Optional WiFi/ GPRS remote monitoring (extral cost)
  • Overload, short circuit, over discharge protection
  • Auto-start the generator ( Dry Contacts for delivering signal)

Inverter Mode

  • Output: Pure Sine Wave
  • Surge Rating: 9000W (20 Seconds)
  • Peak Power : 4500VA
  • AC Output : 120VAC ,50HZ/60HZ
  • Input Voltage / Rated Battery : 24VDC (minimum start-up voltage:22V)
  • Bypass Breaker Current: 40A
  • Idle Power: 50W
  • Power Saver Mode Idle Consumption: 25W

MPPT Solar Charging Mode

  • Maximum Input Power: 1400w
  • PV Charging Current : 0-60A
  • Max.PV Open Circuit Voltage: 100V
  • PV operation voltage range: 30-100VDC
  • Mppt Voltage Range: 30-85VDC
  • Recommended wire: 8 AWG

AC Charging Mode

  • Rated AC input: 110V, 50HZ/60HZ
  • Input Voltage Range: 90VAC-140VAC
  • Conversion Time: 10ms
  • Battery Type: Lead Acid and Lithium Battery
  • Maximum Charging Current: 40A
  • Charging Voltage Range:20-33VDC
  • Short-Circuit Protection: Breakers and fuses
  • Overcharge Protection: Yes. Automatically alerts and turns off charging after 1 min

Mechanical

  • Size: 14.96 x 11.03 x 4.06 inch
  • Net Weight: 6.8KG
  • Noise: ≤60dB
  • Cooling Fan: Yes

SunGoldPower

SunGoldPower 3000W 24V Pure Sine Wave Solar Inverter Charger

$595.00 $1,190.00
Save $595.00
Pay Over Time
  • Flash Sale Going On Now! Get 5% Cash Back with Code FLASH5 (Enter code in checkout) *Brands Excluded: EWheels, Afikim, Avocado, Green Bike USA, Emojo, Pride, Rambo, DWMEIGI, Fiido, Renogy, SunGoldPower, BougeRV, Cycleagle, Mini Motos, Anyhill, and Jackery
  • We Match Any Authorized Dealers Price - Call Us Now For The Best Price: (800) 674-3815 Available: Mon-Sun 8AM-8PM EST
  • Low Monthly Financing Available - Apply For Bread Pay™ Financing In Checkout
  • Fast and Free Shipping To Lower 48 USA
  • Limited Stock On Hand. Order Now Before They’re Gone!
Inventory:

Inventory
Quantity:

Flash Sale Ends 11:59PM EST

Specs

Main Features

  • Built-in 60A MPPT solar charge controller, max PV input 1400W
  • 40A Smart AC charger
  • High frequency transformer-less compact design
  • Pure sine wave AC 120V output with 50hz/60hz switch
  • Optional WiFi/ GPRS remote monitoring (extral cost)
  • Overload, short circuit, over discharge protection
  • Auto-start the generator ( Dry Contacts for delivering signal)

Inverter Mode

  • Output: Pure Sine Wave
  • Surge Rating: 9000W (20 Seconds)
  • Peak Power : 4500VA
  • AC Output : 120VAC ,50HZ/60HZ
  • Input Voltage / Rated Battery : 24VDC (minimum start-up voltage:22V)
  • Bypass Breaker Current: 40A
  • Idle Power: 50W
  • Power Saver Mode Idle Consumption: 25W

MPPT Solar Charging Mode

  • Maximum Input Power: 1400w
  • PV Charging Current : 0-60A
  • Max.PV Open Circuit Voltage: 100V
  • PV operation voltage range: 30-100VDC
  • Mppt Voltage Range: 30-85VDC
  • Recommended wire: 8 AWG

AC Charging Mode

  • Rated AC input: 110V, 50HZ/60HZ
  • Input Voltage Range: 90VAC-140VAC
  • Conversion Time: 10ms
  • Battery Type: Lead Acid and Lithium Battery
  • Maximum Charging Current: 40A
  • Charging Voltage Range:20-33VDC
  • Short-Circuit Protection: Breakers and fuses
  • Overcharge Protection: Yes. Automatically alerts and turns off charging after 1 min

Mechanical

  • Size: 14.96 x 11.03 x 4.06 inch
  • Net Weight: 6.8KG
  • Noise: ≤60dB
  • Cooling Fan: Yes

All-in-One Solar Charge Inverter

The 3000W Pure Sine Wave Inverter combined with 60A MPPT solar charging and 40A AC battery charging, you can enjoy the stable power from the sun and the utility grid to keep you powered under any circumstances.

Uninterrupted Power Supply

If the main or generator is disconnected or if the solar charging is insufficient, the Inverter Charger takes over the battery supply within 10 milliseconds so that your electronics will never lose power! Includes short circuit protection, over voltage and under voltage, protection, overload protection, reverse protection, etc.
